On this page, you can find all the essential technical data on the ULT Freezer. Our customer relations team will be pleased to help if you want further information. If you should require a customised special solution, please contact our technical specialists at [email protected].
Range of functions
| Adjustable parameters | Temperature |
|---|---|
| Control unit | 7” touchscreen integrated in the outer door in ergonomic position |
Temperature
| Setting temperature range | -50 to -86 °C |
|---|---|
| Setting accuracy temperature | 0.1 °C |
Communication
| Interface | Ethernet LAN, USB |
|---|
Safety
| Power failure | Backup battery for alarming and monitoring during power failure |
|---|---|
| Temperature monitoring | Temperature sensor Pt1000 |
| Alarm | visual and acoustic |
Standard equipment
| Standard option | Door-open detection; Entry port / pressure relief opening Ø 26 mm, lateral, Battery-backed alarm system |
|---|---|
| Door | Insulated stainless steel outer doors with mechanical door lock |
| Additional accessories | Standard interior configuration with 4 compartments. Consisting of 2 stainless steel inner doors and 3 height-adjustable shelves for flexible adaptation to different load sizes. |
Stainless steel interior
| Dimensions | w(A) x h(B) x d(C): 1035 x 1276 x 732 mm |
|---|---|
| Max. number of 2" / 50mm boxes | 770 |
| Volume | 966 l |
| Max. loading of chamber | 440 kg |
| Max. loading per internal | 220 kg |
Textured stainless steel casing
| Dimensions | w(D) x h(E) x d(F): 1285 x 1992 x 973 mm |
|---|---|
| Installation | on lockable castors |
Packing/shipping data
| Customs tariff number | 8418 69 00 |
|---|---|
| Country of origin | Netherlands |
| Transport information | The appliances must be transported upright |
| Dimensions approx incl. carton | w x h x d: 1440 x 2250 x 1080 mm |
| Net weight | approx. 425 kg |
| Gross weight carton | approx. 590 kg |
Standard units are safety-approved and bear the test marks
