On this page, you can find all the essential technical data on the ULT Freezer. Our customer relations team will be pleased to help if you want further information. If you should require a customised special solution, please contact our technical specialists at [email protected].
Range of functions
| Adjustable parameters | Temperature |
|---|---|
| Control unit | 7” touchscreen integrated in the outer door in ergonomic position |
Temperature
| Setting temperature range | -50 to -86 °C |
|---|---|
| Cooling system | Cooling system with two (2) cascade-connected compressors for reliable low-temperature performance. Refrigerants: First stage R455A / Second stage R170. Air-cooled condenser. |
| Setting accuracy temperature | 0.1 °C |
Communication
| Interface | Ethernet LAN, USB |
|---|
Safety
| Power failure | Backup battery for alarming and monitoring during power failure |
|---|---|
| Temperature monitoring | Temperature sensor Pt1000 |
| Alarm | visual and acoustic |
Standard equipment
| Standard option | Door-open detection; Entry port / pressure relief opening Ø 26 mm, lateral, Battery-backed alarm system |
|---|---|
| Door | Insulated stainless steel outer doors with mechanical door lock |
| Additional accessories | Standard interior configuration with 4 compartments. Consisting of 2 stainless steel inner doors and 3 height-adjustable shelves for flexible adaptation to different load sizes. |
Stainless steel interior
| Dimensions | w(A) x h(B) x d(C): 890 x 1345 x 627 mm |
|---|---|
| Max. number of 2" / 50mm boxes | 576 |
| Volume | 750 l |
| Max. loading of chamber | 400 kg |
| Max. loading per internal | 200 kg |
Textured stainless steel casing
| Dimensions | w(D) x h(E) x d(F): 1140 x 2000 x 888 mm |
|---|---|
| Installation | on lockable castors |
Packing/shipping data
| Country of origin | Netherlands |
|---|---|
| Transport information | The appliances must be transported upright |
| Dimensions approx incl. carton | w x h x d: 1410 x 2220 x 1080 mm |
| Net weight | approx. 380 kg |
| Gross weight carton | approx. 550 kg |
Standard units are safety-approved and bear the test marks
