| Model sizes | 30 | 55 | 110 | 260 | 410 | 750 | 1060 | 1400 | 2200 | |
|---|---|---|---|---|---|---|---|---|---|---|
| Temperature restriction; Temperature: +60 °C | A8 | A8 | A8 | A8 | A8 | A8 | A8 | |||
| Chamber modification for the application of reinforced perforated stainless steel shelves or stainless steel grids (bearing rails mounted in the working chamber) - includes replacement of standard grids by reinforced grids (standard with 1060) | K1 | |||||||||
| Light module cold white 6,500 K: light strips arranged on the side walls of the interior, 10 strips for model 110, 14 for model 260/410/750, programme-controlled dimming from 0 to 100 % (in 1 % steps), ramp programming in combination with temperature (only with TwinDISPLAY; not in combination with F6) | T7 | T7 | T7 | T7 | ||||||
| Light module cold white 6,500 K + warm white 2,700 K: LED light strips - 10 strips for model 110, 14 for model 260/410/750 - (5 resp. 7 alternating cold white light strips and 5 resp. 7 warm white light strips) on the side walls of the interior, programme-controlled dimming from 0 to 100 % (in 1 % steps), ramp programming in combination with temperature (only with TwinDISPLAY; not in combination with F6) | T8 | T8 | T8 | T8 | ||||||
| Light module warm white 2,700 K: light strips arranged on the side walls of the interior, 10 strips for model 110, 14 for model 260/410/750, programme-controlled dimming from 0 to 100 % (in 1 % steps), ramp programming in combination with temperature (only with TwinDISPLAY; not in combination with F6) | T9 | T9 | T9 | T9 | ||||||
| Interior socket (can only be ordered with limited temperature range - max. +60 °C), ampacity 230V/2, 2A/500W, can be switched off with the On/Off switch, cannot be switched individually, moisture tight IP68 (requires option A8 against surcharge) | R3 | R3 | R3 | R3 | R3 | R3 | R3 | |||
|
Entry port, 23 mm clear diameter, for introducing connections at the side, can be closed by flap, standard positions (F0 and F2 not for model size 260 with light module; F0 - F3 not for model size 110 with light module), position left centre/centre | F0 | F0 | F0 | F0 | F0 | F0 | F0 | ||
|
|
Entry port, 23 mm clear diameter, for introducing connections at the side, can be closed by flap, standard positions (F0 and F2 not for model size 260 with light module; F0 - F3 not for model size 110 with light module), position left centre top | F1 | F1 | F1 | F1 | F1 | F1 | F1 | ||
|
Entry port, 23 mm clear diameter, for introducing connections at the side, can be closed by flap, standard positions (F0 and F2 not for model size 260 with light module; F0 - F3 not for model size 110 with light module), position right centre/centre | F2 | F2 | F2 | F2 | F2 | F2 | F2 | ||
|
Entry port, 23 mm clear diameter, for introducing connections at the side, can be closed by flap, standard positions (F0 and F2 not for model size 260 with light module; F0 - F3 not for model size 110 with light module), position right centre top | F3 | F3 | F3 | F3 | F3 | F3 | F3 | ||
|
Entry port, 23 mm clear diameter for introducing connections at the side, can be closed by flap in special positions (please, state location) - left | F4 | F4 | F4 | F4 | F4 | F4 | F4 | F4 | F4 |
|
Entry port, 23 mm clear diameter for introducing connections at the side, can be closed by flap in special positions (please, state location) - right | F5 | F5 | F5 | F5 | F5 | F5 | F5 | F5 | F5 |
|
Entry port, 23 mm clear diameter, can be closed by flap in special positions (please, state location) – rear | F6 | F6 | F6 | F6 | F6 | F6 | F6 | ||
| Entry port (silicone), 40 mm clear diameter, moisture tight, can be closed by silicone stopper, at the back (please state location) | F7 | F7 | F7 | F7 | F7 | F7 | F7 | |||
| Entry port (silicone), 40 mm clear diameter, moisture tight, can be closed by silicone stopper, standard position rear | D8 | D8 | D8 | D8 | D8 | D8 | D8 | |||
| 4 – 20 mA current loop interface (-10 to +80°C corresponds to 4 – 20 mA), temperature controller actual value | V3 | V3 | V3 | V3 | V3 | V3 | V3 | V3 | V3 | |
|
Door with lock and key (safety lock) | B6 | B6 | B6 | B6 | B6 | B6 | B6 | ||
| Door with lock and key (safety lock), two locks (one each door) | B62 | |||||||||
| Door with lock and key (safety lock), three locks (one each door) | B63 | |||||||||
| Door hinged on the left | B8 | B8 | B8 | B8 | B8 | |||||
|
Potential-free contact for combination error message (e.g. supply failure, sensor fault, fuse) | H6 | H6 | H6 | H6 | H6 | H6 | H6 | H6 | H6 |
| Process-dependent programmable door lock (only for units with TwinDISPLAY) | D4 | D4 | D4 | D4 | D4 | D4 | D4 | |||
| Process-dependent programmable door lock, two interlocking systems (one each other) | D42 | |||||||||
| Process-dependent programmable door lock, three interlocking systems (one each other) | D43 | |||||||||
| Door-open-recognition (only for units with TwinDISPLAY) | V5 | V5 | V5 | V5 | V5 | V5 | V5 | |||
| Door-open-recognition, two (one each door) | V52 | |||||||||
| Door-open-recognition, three (one each door) | V53 | |||||||||
| MobileALERT, notification by SMS in case of any error or alarm of the device (Requires option H6) | C3 | C3 | C3 | C3 | C3 | C3 | C3 | C3 | C3 | |
|
Castor frame (2-part), height 140 mm | R9 | R9 | R9 | R9 |
| Model sizes | 30 | 55 | 110 | 260 | 410 | 750 | 1060 | 1400 | 2200 | |
|---|---|---|---|---|---|---|---|---|---|---|
|
Stainless steel grids, electropolished | E28884 | E20164 | E20165 | E28891 | E28891 | E20182 | B41251 | B38955 | B38955 |
| Reinforced stainless steel grid, max. loading 60 kg (size 750 with guide bars and fixing screws and only in connection with option K1). Please consider max. loading of chamber. | E29767 | E29766 | E29766 | B32190 | B32550 | |||||
|
Perforated stainless steel shelf | B29727 | B03916 | B00325 | B29725 | B29725 | B00328 | |||
|
Reinforced perforated stainless steel shelves, max. loading 60 kg, with guide bars and fixing screws and only in connection with option K1. Please consider max. loading of chamber | B32191 | B32549 | |||||||
| Stainless steel slide-in drip tray, 15 mm rim (may affect the temperature distribution) - cannot be used in connection with option K1 | E02070 | E02072 | E02073 | E29726 | E29726 | E02075 | B32599 | |||
| Stainless steel slide-in drip tray, 15 mm rim, with guide bars and fixing screws (may affect the temperature distribution) - can be used only in connection with option K1 | B32763 | |||||||||
| Stainless steel bottom drip tray, 15 mm rim (may affect the temperature distribution) - cannot be used in connection with option K1 | B04356 | B04358 | B04359 | B29722 | B29722 | B04362 | B29769 | |||
| Stainless steel bottom drip tray, 15 mm rim (may affect the temperature distribution) - can be used only in connection with option K1 | B34055 | |||||||||
| Max. loading per slide-in drip tray (kg) | 1,5 | 1,5 | 3 | 4 | 4 | 8 | 8 | |||
| Max. loading per bottom drip tray (kg) | 1,5 | 1,5 | 3 | 4 | 4 | 8 | 8 | |||
| USB-Ethernet adapter | E06192 | E06192 | E06192 | E06192 | E06192 | E06192 | E06192 | E06192 | E06192 | |
| Ethernet connection cable 5 m for computer interface | E06189 | E06189 | E06189 | E06189 | E06189 | E06189 | E06189 | E06189 | E06189 | |
| USB User-ID stick (with User-ID licence): Oven-linked authorisation licence (User-ID-programme) on Memory-stick, prevents undesired manipulation by unauthorised third parties. When reordering please specify serial number (only for units with TwinDISPLAY) | B33170 | B33170 | B33170 | B33170 | B33170 | B33170 | B33170 | B33170 | B33170 | |
| USB stick with documentation software AtmoCONTROL and operation manual for products with SingleDISPLAY (the standard equipment of appliances with TwinDISPLAY includes one USB stick with AtmoCONTROL) USB stick with documentation software AtmoCONTROL and operation manual for products with SingleDISPLAY (the standard equipment of appliances with TwinDISPLAY includes one USB stick with AtmoCONTROL). When reordering please specify serial number | B33172 | B33172 | B33172 | B33172 | B33172 | B33172 | B33172 | B33172 | B33172 | |
| Set of height adjustable feet (4 pcs) | B29768 | B29768 | B29768 | B29768 | ||||||
|
Stacking set (4 pcs) for stacking of appliances of same size | B29744 | B29744 | B29744 | ||||||
|
Flush-fit unit (stainless steel frame covering gap between oven and wall opening), with air slots – technical clarification required | B29728 | B29730 | B29734 | B29738 | B42116 | B29742 | B29742 | ||
|
Flush-fit unit (stainless steel frame covering gap between oven and wall opening), without air slots – technical clarification required | B29729 | B29731 | B29735 | B29739 | B42117 | B29743 | B29743 | ||
|
Subframe, adjustable in height (size 30 and 55: height 600 mm, size 110 and 260: height 500 mm) | B29745 | B29747 | B29749 | B29751 | |||||
|
Subframe, on castors (size 30 and 55: height 660 mm, size 110: height 560 mm) | B29746 | B29748 | B29750 | ||||||
| Subframe, adjustable in height, height 130 mm | B33657 | B33659 | B33661 | B33664 | ||||||
| Software conforming to FDA AtmoCONTROL. Meets the requirements for the use of electronically stored data sets and electronic signatures as laid down in Regulation 21 CFR Part 11 of the US Food and Drug Administration (FDA). Base licence for the control of one unit (only for units with TwinDISPLAY). Respective IQ/OQ documents available in German and English language (without surcharge) | FDAQ1 | FDAQ1 | FDAQ1 | FDAQ1 | FDAQ1 | FDAQ1 | FDAQ1 | FDAQ1 | FDAQ1 | |
| Integration of one additional unit (up to max. 31 units) into an already existent FDA-software licence (only for units with TwinDISPLAY) | FDAQ2 | FDAQ2 | FDAQ2 | FDAQ2 | FDAQ2 | FDAQ2 | FDAQ2 | FDAQ2 | FDAQ2 | |
| External measuring instrument with sensors for daylight and UV-light. Product information on demand (models HPPeco, ICHLeco/ ICHL, IPPecoplus) | B04713 | B04713 | B04713 | B04713 | B04713 | B04713 | ||||
| External measuring instrument with sensors with additional measuring head for temperature and humidity measurement. Product information on demand (models HPPeco, ICHeco/ICH, ICHLeco/ICHL, IPPecoplus and ICOmed) | B04714 | B04714 | B04714 | B04714 | B04714 | B04714 | B04714 | B04714 | B04714 |
| Model sizes | 30 | 55 | 110 | 260 | 410 | 750 | 1060 | 1400 | 2200 | |
|---|---|---|---|---|---|---|---|---|---|---|
| Guarantee extension by 1 year | GA1Q5 | GA1Q5 | GA1Q5 | GA2Q5 | GA2Q5 | GA2Q5 | GA4Q5 | GA4Q5 | GA4Q5 | |
| Calibration at Memmert factory for a freely selectable temperature value | D00109 | D00109 | D00109 | D00109 | D00109 | D00109 | D00109 | D00109 | D00109 | |
|
Calibration at Memmert factory for three temperature values: +5, +37, +60 °C | D00129 | D00129 | D00129 | D00129 | D00129 | D00129 | D00129 | ||
| DAkkS calibration for one free-selectable temperature value according to method C (DKD-R 5-7) | E39696 | E39696 | E39696 | E39696 | E39696 | E39696 | E39696 | E39696 | E39696 | |
| Extension of DAkkS calibration at Memmert factory by an additional freely selectable temperature value according to method C (DKD-R 5-7) | E39697 | E39697 | E39697 | E39697 | E39697 | E39697 | E39697 | E39697 | E39697 | |
| IQ document with device-specific works test data, OQ/PQ check list as support for validation by customer | D00124 | D00124 | D00124 | D00124 | D00124 | D00124 | D00124 | D00124 | D00124 | |
| IQ/OQ document with device-specific works test data, including temperature distribution survey with 9 temperature measuring points (size 30), 27 temperature measuring points (sizes 55 - 1060, 2200) and 26 temperature measuring points (size 1400) at Memmert factory for a freely selectable temperature value according to DIN12880:2007-05 (PQ check list as support for validation by customer) | D00125 | D00127 | D00127 | D00127 | D00127 | D00127 | D00127 | D00127 | D00127 | |
| Extension of IQ/OQ document at Memmert factory by an additional freely selectable temperature value | D49121 | D49121 | D49121 | D49121 | D49121 | D49121 | D49121 | D49121 | D49121 | |
| Short training on the handling and use of the device on site (outside Germany price on request) | S49128 | S49128 | S49128 | S49128 | S49128 | S49128 | S49128 | S49128 | S49128 | |
| Calibration on site for a freely selectable temperature value (travel costs are not included yet) | S00205 | S00205 | S00205 | S00205 | S00205 | S00205 | S00205 | S00205 | S00205 | |
| Extension of calibration on site by an additional freely selectable temperature value | S00215 | S00215 | S00215 | S00215 | S00215 | S00215 | S00215 | S00215 | S00215 | |
| DAkkS calibration on site for a freely selectable temperature value according to method C (DKD-R 5-7) (travel costs are not included yet) | S00360 | S00360 | S00360 | S00360 | S00360 | S00360 | S00360 | S00360 | S00360 | |
| IQ/OQ qualification on site including temperature distribution survey with 9 temperature measuring points (size 30), 27 temperature measuring points (sizes 55 - 1060, 2200) and 28 temperature measuring points (size 1400) for a freely selectable temperature value according to DIN12880:2007-05 (travel costs are not included yet) | DLQ100 | DLQ100 | DLQ100 | DLQ100 | DLQ100 | DLQ100 | DLQ100 | DLQ100 | DLQ100 | |
| OQ requalification on site including temperature distribution survey with 9 temperature measuring points (size 30), 27 temperature measuring points (sizes 55 - 1060, 2200) and 26 temperature measuring points (size 1400) for a freely selectable temperature value according to DIN12880:2007-05 (travel costs are not included yet) | DLQ100R | DLQ100R | DLQ100R | DLQ100R | DLQ100R | DLQ100R | DLQ100R | DLQ100R | DLQ100R | |
| Extension of IQ/OQ qualification or OQ requalification on site by an additional freely selectable temperature value | DLQ100A | DLQ100A | DLQ100A | DLQ100A | DLQ100A | DLQ100A | DLQ100A | DLQ100A | DLQ100A | |
| PQ qualification on site (travel costs are not included yet) | DLQ200 | DLQ200 | DLQ200 | DLQ200 | DLQ200 | DLQ200 | DLQ200 | DLQ200 | DLQ200 | |
| Maintenance on site IPP/ IPPeco according to Memmert maintenance plan (available on request) (travel costs are not included yet) | S00317 | S00317 | S00317 | S00317 | S00317 | S00317 | S00317 | S00317 | S00317 | |
| Maintenance contract on site IPP/ IPPeco according to Memmert maintenance plan (available on request), minimum duration 3 years (travel costs are not included yet) | S00317J | S00317J | S00317J | S00317J | S00317J | S00317J | S00317J | S00317J | S00317J |
